Checking the Inputs and Outputs ESIE07-04
3–10 Part 3 – Troubleshooting
3
1
3
4
5
2.4 List of Digital Outputs
The table below gives an overview of all the digital outputs.
Notes (*) If Thermostatic expansion valve is used. Fourth step fan # 1 if electronic expansion valve is used
(**) If Thermostatic expansion valve is used. Fourth step fan # 2 if electronic expansion valve is used
(***) If Thermostatic expansion valve is used. Fourth step fan # 3 if electronic expansion valve is used
(****) If Thermostatic expansion valve is used. Fourth step fan # 4 if electronic expansion valve is used
N BOARD # 1 BOARD # 2
1 Start Compressor # 1 Start Compressor # 3
2 Load Compressor # 1 Load Compressor # 3
3 Unload Compressor # 1 Unload Compressor # 3
4 Liquid Injection # 1 Liquid Injection # 3
5 Liquid Line # 1 (*) Liquid Line # 3 (***)
6 First step fan # 1 First step fan # 3
7 Second step fan # 1 Second step fan # 3
8 Third step fan # 1 Third step fan # 3
9 Start Compressor # 2 Start Compressor # 4
10 Load Compressor # 2 Load Compressor # 4
11 Unload Compressor # 2 Unload Compressor # 4
12 Evaporator water pump ---
13 Unit Alarm ---
14 Liquid Injection # 2 Liquid Injection # 4
15 Liquid Line # 2 (**) Liquid Line # 4 (****)
16 First step fan # 2 First step fan # 4
17 Second step fan # 2 Second step fan # 4
18 Third step fan # 2 Third step fan # 4
