Pre-Test Run Checks ESIE07-04
4–8 Part 4 – Commissioning and Test Run
3
1
4
5
1.5 Water Pressure Drop: Table for Matching Unit Sizes
Table
Note: Unit size matching system used for evaporator pressure drop curves, partial heat recovery ratings and
pressure drop curves for partial and total heat recovery.
Unit size ST /A /Q /Z
A - - 550 600
B 650 650 600 650
C 700 700 650 700
D 750 800 700 -
E 850 850 750 -
F - 800 850
G 900 900 - -
H - 950 - -
I - 850 900
J-C10--
K 950 C11 900 950
L C10 C12 950 C10
MC11C13C10 -
NC12C14C11 -
O C13 C15 C12 -
PC14C16 - -
Q-C17- -
RC15C18 - -
SC16C19 - -
TC18C20 - -
U-C21- -
