ASRock EP2C622D24LM [10/97] English
![ASRock EP2C622D24LM [10/97] English](/views2/1694459/page10/bga.png)
4 5
English
Fan - CPU/Front Fan Tachometer
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
- CPU/Front Fan Multi-Speed Control
Voltage Voltage Monitoring: +12V, +5V, +3V, BAT, 1.8V_PCH, 1.05V_
PCH, PVNN_PCH, VCCM_ABC, VCCM_DEF, VCCM_
GHI, VCCM_JKL, CPU1_VCORE, CPU2_VCORE, +5VSB,
+3VSB
Support OS
OS Microso® Windows® (Server OS)
- Server 2012 R2 (64 bit)
- Server 2016 (64 bit)
Linux®
- RedHat Enterprise Linux Server 6.8 (64 bit) / 7.4 (64 bit) -
CentOS 6.8 (64 bit) / 7. 4 (64 bit)
- SUSE Enterprise Linux Server 11 SP4 (64 bit) /12 SP3 (64 bit)
- FreeBSD 11 (64 bit)
- Fedora Core 24 (64 bit)
- Ubuntu 16.04/15.10 (64 bit)
Virtual:
- VMWare ESXi 6.5
*
Please refer to our website for the latest OS support list.
*Before installing the Linux OS, please rst enter the BIOS settings, go to
“Advanced” > “Chipset Conguration” and set “IGPU Multi-Monitor” option
to “Disabled”.
Environment
Temperature Operation temperature: 10°C ~ 35°C / Non operation
temperature: -40°C ~ 70°C
is motherboard supports Wake from on Board LAN. To use this function, please make
sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager
> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is
enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard
LAN1&2 can wake up S5 under OS.
If you install Intel® LAN utility or Marvell SATA utility, this motherboard may fail Win-
dows® Hardware Quality Lab (WHQL) certication tests. If you install the drivers only, it
will pass the WHQL tests.
NOTE: Please refer to our website for the latest specications.
