EP2C626D24LM / EP2C622D24LM / EP2C621D24LM-AB
2 3
English
IPMI Dedicated
GLAN
1 x Realtek RTL8211E for dedicated management GLAN
Features - Watch Dog
- NMI
Graphics
Controller ASPEED AST2500
VRAM DDR4 16MB
Rear Panel I/O
VGA Port 1 (D-sub)
USB 3.0 Port 2
LAN Port - 1 x RJ45 Dedicated IPMI LAN port
- LAN Ports with LED (ACT/LINK LED and SPEED LED)
UID Buttom/LED 1
Serial port 1 (COM1)
Internal Connector
Auxiliary Panel
Header
1 (includes chassis intrusion , location button & LED , front
LAN LED)
SATA DOM 2
SATA Port 12 from MiniSAS HD connector
TPM Header 1
SMB Header 3
IPMB Header 1
Fan Header EP2C626D24LM / EP2C622D24LM:
6 x System Fans (6-pin)
EP2C621D24LM-AB:
4 x Front Fans (6-pin) + 2 x CPU Fans (6-pin)
Power CRPS (+12V/+12VSB IN)
Type A USB 3.0 Port 1
Internal VGA header 1
USB 3.0 Header 1 (supports 2 USB 3.0 ports)
USB 2.0 Header 1 (supports 2 USB 2.0 ports)
M.2 2 (2230 / 2242 / 2260 / 2280, support PCIE (x2) or SATA3 M.2)
System BIOS
BIOS Ty pe 256Mb AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8 Support
- ASRock Rack Instant Flash
Hardware Monitor
Temperature - CPU Temperature Sensing
- System Temperature Sensing
- Card Side Temperature Sensing
