ASRock EP2C622D24LM [40/97] English
![ASRock EP2C622D24LM [40/97] English](/views2/1694459/page40/bg28.png)
34 35
English
EP2C626D24LM /
EP2C622D24LM:
System Fan Connectors
(6-pin SYS _FAN1)
(see p.6, No. 26)
(6-pin SYS_FAN2)
(see p.6, No. 23)
(6-pin SYS_FAN3)
(see p.6, No. 21)
(6-pin SYS_FAN4)
(see p.6, No. 18)
(6-pin SYS_FAN5)
(see p.6, No. 15)
(6-pin SYS_FAN6)
(see p.6, No. 13)
Please connect system fans to
the fan connectors.
TPM Header
(17-pin TPM1)
1
GN
D
SMB_ DATA_MAIN
LAD2
LAD1
GND
S_PW RDWN#
SERI RQ#
GN
D
PCICL
K
PCIR ST#
LAD3
+3V
LAD0
+3VSB
GND
LFRA ME#
SMB_ CLK_MAIN
is connector supports
Trusted Platform Module
(TPM) system, which can
securely store keys, digital
certicates, passwords, and
data. A TPM system also helps
enhance network security,
protects digital identities, and
ensures platform integrity.
Non Maskable Interrupt
Button Header
(2-pin NMI_BTN1)
1
CONTROL
GND
Please connect a NMI device
to this header.
1
GND
TACH_FRNT_R_FAN2
PWM_FRNT_FAN2_R_BUF
SYS_FAN4_Fault
SYS_FAN4_PRSNT_N
+12V
