EP2C626D24LM / EP2C622D24LM / EP2C621D24LM-AB
90 91
English
Appendix A
Mezzanine Card Support List
is motherboard supports the following ASRock Rack mezzanine cards.
Mezz Card Type Mezz Slot Type Supported MB Model Model
LAN Card Mezz Type A
EP2C626D24LM
EP2C622D24LM
EP2C621D24LM-AB
M350
LAN Card Mezz Type A M350R
LAN Card Mezz Type A M540
LAN Card Mezz Type A M540R
LAN Card Mezz Type A M599
LAN Card Mezz Type A M599R
LAN Card Mezz Type A M710
LAN Card Mezz Type A MX710R
Storage Card Mezz Type A M3008
Storage Card Mezz Type A M3008S
Storage Card Mezz Type A M3108
Storage Card Mezz Type A M3616
PHI Card Mezz Type C
EP2C626D24LM
EP2C622D24LM
MP-557R2
PHI Card Mezz Type C MP-1543R4
PHI Card Mezz Type C MP-4227R2
*Please refer to our website for the latest support list.
*Due to mechanical limits, use one type of the mezzanine card at a time.
