ASRock EP2C622D24LM [14/97] English
![ASRock EP2C622D24LM [14/97] English](/views2/1694459/page14/bge.png)
8 9
English
6No. Description
34 USB 2.0 Header (USB_1_2)
35 M.2 Socket (M2_1) (Type 2230/2242/2260/2280)
36 ESPI / LPC Switch Jumper (ESPI_LPC_SW1)
37 Front LAN LED Header (FRONT_LED_LAN34)
38 PMBUS Mode Jumper (PMBUS_SEL_CLK1)
39 PMBUS Mode Jumper (PMBUS_SEL_ALT1)
40 PMBUS Mode Jumper (PMBUS_SEL_DAT1)
41 Chassis ID2 Jumper (CHASSIS_ID2)
42 Chassis ID1 Jumper (CHASSIS_ID1)
43 Non Maskable Interrupt Button (NMI_BTN1)
44 Chassis ID0 Jumper (CHASSIS_ID0)
45 NCSI Mode Jumper (NCSI_SEL1)
46 Enable/Disable BMC Jumper (BMC_DIS1)
47 Speaker Header (SPEAKER1)
48 NCSI Mode Jumper (NCSI_SEL2)
49 Mezzanine Card Slot (MEZZ_MB_A1)
50 ME Recovery Jumper (ME_RECOVERY1)
51 Security Override Jumper (SEC_OR1)
52 Mezzanine Card Slot (MEZZ_MB_C1)
53 Mezzanine Card Slot (MEZZ_MB_B1)
54 Mini SAS HD Connector (SSATA_2_5)**
55 PCI Express 3.0 Slot (CPU1_PCIE1)
56 Vertical Type A USB 3.0 (USB3_5)
57 TPM Header (TPM1)
58 SATA DOM Connector (SSATA_0)**
59 Front VGA Header (FRONT_VGA1)
60 SATA DOM Power Jumper (SSATAPWR2)**
61 Mezzanine Card Slot (MEZZ_MB_A2)
62 SATA DOM Power Jumper (SSATAPWR1)**
63 SATA DOM Connector (SSATA_1)
64 Mezzanine Card Slot (MEZZ_MB_B2)
65 PCI Express 3.0 Slot (CPU2_PCIE1)
66 PCI Express 3.0 Slot (CPU2_PCIE2)
67 Slimline NVMe Connector (SLIMLINE1)
