16 17

English

1.7 Block Diagram

EP2C626D24LM / EP2C622D24LM

UPI0

UPI1

10.4GTps (SKX)

11.2GTps (CNX )

DDR 4 CHA

DDR 4 CHB

DDR 4 CHC

DDR 4 CHD

DDR 4 CHE

DDR 4 CHF

DDR 4 RDI MM up to 2666Mh z

DDR 4 RDI MM up to 2666Mh z

PCIe x16 Gen 3

Port:2A-2D

MEZ Z x16(NIC OCP 2.0)

PCIe x16 Gen 3 Port:3A-3D

DDR 4 CHA

DDR 4 CHB

DDR 4 CHC

DDR 4 CHD

DDR 4 CHE

DDR 4 CHF

Skylake

Up t o 245W

Skylake

Up t o 245W

DMI3 x4

PCIE Gen3 x2(Share with sSATA 0)

USB3.0 x1

Int el

Lewisburg

C62X

Socket 1

Skylake-EP

Socket 2

Skylake-EP

SATA 0-7

PCIe x16

PCIe x8 Gen 3 Port:2C-2D

PCIe x16 Gen 3 Port:1A-1D

PCIe x16

BMC SPI

NCS I

PCIe x8 Gen 3 Port:1A-1B to Mezz Type A

PCIe x8 Gen 3 Port:1C-1D to Mezz Type B

BMC

Flash

DDR 4

USB2.0 x2

PCIe Gen2 x1

EP2C622 D24LM MB Bl ock Diagram

Rev 1.0

PCIe x16 Gen 3 Port:3A-3D

sSATA 2-5

sSATA 0-1

(SATA DOM)

sSATA x2

sSATA x4

SATA x8(Share with QAT)

USB3.0 X1

KR X 4

Mezz Type C

Type-A

USB3.0 X2

RTL 8211E

1G/100M MNG NIC

RGB

RJ-45

RGMI I

D-SUB

MEZ Z x16(STO RAG E)

Swit ch

System SPI

LPC

SPI

TPM/T CM

Header

BIOS

Flash

PWM F AN X6

Serial port

COM-POR T

UID

PCIE Gen3 x2(Share with sSATA 1)

LPC

PCIe x8

PCIe x8 Gen 3 Port:2A-2B(Share with QAT)

M.2(2280)

M.2(2280)

USB3.0 X1

USB2.0 X2

Front VGA Header
