EP2C626D24LM / EP2C622D24LM / EP2C621D24LM-AB
10 11
English
No. Description
1 PSU Connector 2 (PSU_CON2)
2 PSU Connector 1 (PSU_CON1)
3 HDD Power Connetor (HDD_PWR1)
4 Backplane Power Connector (HSBP_PWR1)
5 Virtual RAID On CPU Header (RAID_1)
6 BMC SMBus Header 1 (BMC_SMB_1)
7 BMC SMBus Header 2 (BMC_SMB_2)
8 BMC SMBus Header 3 (BMC_SMB_3)
9 Intelligent Platform Management Bus header (IPMB_1)
10 Backplane PCI Express Hot-Plug Connector (HSBP_CPU2_1)
11 3 x 288-pin DDR4 DIMM Slots (DDR4_G1, DDR_H1, DDR4_I1, Blue)*
12 3 x 288-pin DDR4 DIMM Slots (DDR4_G2, DDR_H2, DDR4_I2, White)*
13 Front Fan Connector (FRNT_FAN4)
14 CPU Socket 2 LGA-3647 (Socket P) (CPU2)
15 CPU Fan Connector (CPU2_FAN1)
16 3 x 288-pin DDR4 DIMM Slots (DDR4_J2, DDR_K2, DDR4_L2, White)*
17 3 x 288-pin DDR4 DIMM Slots (DDR4_J1, DDR_K1, DDR4_L1, Blue)*
18 Front Fan Connector (FRNT_FAN3)
19 3 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR_B1, DDR4_C1, Blue)*
20 3 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR_B2, DDR4_C2, White)*
21 Front Fan Connector (FRNT_FAN2)
22 CPU Socket 1 LGA-3647 (Socket P) (CPU1)
23 CPU Fan Connector (CPU1_FAN1)
24 3 x 288-pin DDR4 DIMM Slots (DDR4_D2, DDR_E2, DDR4_F2, White)*
25 3 x 288-pin DDR4 DIMM Slots (DDR4_D1, DDR_E1, DDR4_F1, Blue)*
26 Front Fan Connector (FRNT_FAN1)
27 Backplane PCI Express Hot-Plug Connector (HSBP_CPU1_1)
28 System Panel Header (PANEL1)
29 Mini SAS HD Connector (SATA_0_7)
30 SSATA SGPIO Connector (SSATA_SGPIO1)**
31 M.2 Socket (M2_2) (Type 2230/2242/2260/2280)
32 Auxiliary Panel Header (AUX_PANEL1)
33 USB 3.0 Header (USB3_3_4)
