ASRock EP2C622D24LM [8/97] Specifications
![ASRock EP2C622D24LM [8/97] Specifications](/views2/1694459/page8/bg8.png)
2 3
English
1.2 Specications
EP2C626D24LM / EP2C622D24LM / EP2C621D24LM-AB
MB Physical Status
Form Factor L shape
Dimension 16.7" x 17"(42.4 cm x 43.2 cm)
Processor System
CPU Intel® Xeon® Scalable Processor
Socket Dual Socket P, LGA3647
Chipset EP2C626D24LM:
Intel® C626
EP2C622D24LM:
Intel® C622
EP2C621D24LM-AB:
Intel® C621
System Memory
Capacity 24 x 288-pin DDR4 DIMM slots
Type - 6 Channels memory technology
- Supports DDR4 2666/2400/2133 R DIMM/LR DIMM
DIMM Size - RDIMM:32GB, 16GB, 8GB, 4GB
- LRDIMM:64GB, 32GB
Voltage 1.2V
Expansion Slot
PCIe 3.0 x16 2 (Slot1:x16 from CPU1, Slot 2 : x16 from CPU2)
PCIe 3.0 x8 1 (Slot 3 from CPU2)
OCUlink for U.2 N/A
Mezzanine EP2C626D24LM / EP2C622D24LM:
OCP A/B/C for CPU1 and Storage A/B for CPU2
EP2C621D24LM-AB:
OCP A/B for CPU1 and Storage A/B for CPU2
Storage
SATA Controller Intel® C626/C622/C621: 14 SATA3(including 2x M.2 ports or
2x SATA DOM)
Additional Storage
Controller
N/A
Slimline for U.2 1 x8 from CPU2 (support QAT2 by cable to PCH miniSAS HD)
Ethernet
Interface N/A
LAN controller N/A
Management
BMC Controller ASPEED AST2500
