14 15
English
1.5 Onboard LED Indicators
CPU2
CPU1
DDR4_H2(64 bit, 288-pin module, White)
DDR4_H1(64 bit, 288-pin module, Blue)
DDR4_I2White(64 bit, 288-pin module, )
DDR4_I1 (64 bit, 288-pin module, Blue)
DDR4_G2 White(64 bit, 288-pin module, )
DDR4_G1 (64 bit, 288-pin module, Blue)
DDR4_K1(64 bit, 288-pin module, )Blue
DDR4_K2(64 bit, 288-pin module, )White
DDR4_J1 Blue(64 bit, 288-pin module,)
DDR4_J2 (64 bit, 288-pin module,)White
DDR4_L1(64 bit, 288-pin module,)Blue
DDR4_L2 (64 bit, 288-pin module,)White
DDR 4_B2 (6 4 bit, 28 8-pin m odule , White )
DDR 4_B1 (6 4 bit, 28 8-pin m odule , Blue)
DDR 4_C2 (6 4 bit, 28 8-pin m odule , )Whit e
DDR 4_C1 (6 4 bit, 28 8-pin m odule , Blue)
DDR 4_A2 (6 4 bit, 28 8-pin m odule , )Whit e
DDR 4_A1 (6 4 bit, 28 8-pin m odule , Blue)
DDR 4_E1 (6 4 bit, 28 8-pin m odule , )Blue
DDR 4_E2 (6 4 bit, 28 8-pin m odule , )Whit e
DDR 4_D1 B lue(64 b it, 288 -pin mo dule, )
DDR 4_D2 (6 4 bit, 28 8-pin m odule , )Whit e
DDR 4_F1 B lue(64 b it, 288 -pin mo dule, )
DDR 4_F2 (6 4 bit, 28 8-pin m odule , )Whit e
1
1
NUT80_1
M2_1
NUT80_2
M2_1
1
1
1
1
1
FRNT_FAN4
CPU2_FAN1
FRNT_FAN3
FRNT_FAN2
CPU1_FAN1
FRNT_FAN1
1
1
1
FRNT_VGA1
1
USB3_5
1
1
HDLED RESET
PLED PWRBTN
1
1
NUT60_1
NUT60_2
NUT42_1
NUT42_2
NUT30_1
NUT30_2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
BATTERY
EP2C621D24LM-AB
CPU1_PCIE1
(Blue)
MEZZ_MB_A1
MEZZ_MB_B1
CPU2_PCIE1
(White)
MEZZ_MB_A2
MEZZ_MB_B2
CPU2_PCIE2
(White)
Ro HS
BMC
Intel
C621
BMC
FW
BIOS
ROM
1
2
3
4
5
6
7
9
10
11
8
No. Item Status Description
1 FRNT_FAN4_LED1 Red Front_FAN4 failed
2 CPU2_FAN1_LED1 Red CPU2_FAN1 failed
3 FRNT_FAN3_LED1 Red Front_FAN3 failed
4 FRNT_FAN2_LED1 Red Front_FAN2 failed
5 CPU1_FAN1_LED1 Red CPU1_FAN1 failed
6 FRNT_FAN1_LED1 Red Front_FAN1 failed
7 HDD_LED Green HDD activity
8 SB_PWR1 Green STB PWR ready
9 LED_CATERR1 Red CPU CATERR error
10 SYS_LED1 Yellow SYS EVENT
11 BLED1 Green BMC heartbeat LED
