![Daikin RXYQ22PY1 [105/398] Basic control](/views2/1711911/page105/bg69.png)
Basic Control Si34-601A
94 Function
2. Basic Control
2.1 Normal Operation
2.1.1 List of Functions in Normal Operation
*1. PI control : Evaporator outlet superheated degree (SH) constant.
*2. PI control : Condenser outlet subcooled degree (SC) constant.
*1 and 2 : Refer “6.6 Electronic expansion valve control” on page 135.
Part Name Symbol
(Electric
Symbol)
Function of Functional Part
Normal Cooling Normal Heating
Compressor (M1C, M2C)
PI control, High pressure
protection, Low pressure
protection, Td protection,
INV protection,
PI control, High pressure
protection, Low pressure
protection, Td protection,
INV protection,
Outdoor unit fan (M1F) Cooling fan control Step 7 or 8
Four way valve 20S1 (Y1R) OFF ON
Main motorized valve EV1 (Y1E) 480 pls PI control
Subcool heat exchanger
electronic expansion valve
EV2 (Y2E) PI control PI control
Hot gas bypass valve SVP (Y1S) OFF
Energized when the system is set
to low pressure control mode
Accumulator oil return valve SV0 (Y2S) ON ON
Indoor unit actuator Normal cooling Normal heating
Fan
Thermostat ON unit Remote controller setting Remote controller setting
Stopping unit OFF OFF
Thermostat OFF unit Remote controller setting LL
Electronic
expansion
valve
Thermostat ON unit Normal opening
*
1 Normal opening
*
2
Stopping unit 0 pls 200 pls
Thermostat OFF unit 0 pls 200 pls
