Model Selection Si34-601A
8 General Information
High COP Series (Energy Saving Series)
HP 16HP 18HP
System name RXYQ16PH RXYQ18PH
Outdoor unit 1 RXYQ8P RXYQ8P
Outdoor unit 2 RXYQ8P RXYQ10P
Outdoor unit 3 – –
Total number of connectable
indoor units
26 29
Total capacity of connectable
indoor units (kW)
22.40~58.24 25.20~65.52
HP 24HP 26HP 28HP 30HP 32HP
System name RXYQ24PH RXYQ26PH RXYQ28PH RXYQ30PH RXYQ32PH
Outdoor unit 1 RXYQ8P RXYQ8P RXYQ8P RXYQ8P RXYQ8P
Outdoor unit 2 RXYQ8P RXYQ8P RXYQ8P RXYQ10P RXYQ12P
Outdoor unit 3 RXYQ8P RXYQ10P RXYQ12P RXYQ12P RXYQ12P
Total number of connectable
indoor units
39 42 45 48 52
Total capacity of connectable
indoor units (kW)
33.60~87.36 36.40~94.64 39.15~101.79 41.95~109.07 44.70~116.22
HP 34HP 36HP 38HP 40HP 42HP 44HP 46HP
System name RXYQ34PH RXYQ36PH RXYQ38PH RXYQ40PH RXYQ42PH RXYQ44PH RXYQ46PH
Outdoor unit 1 RXYQ10P RXYQ12P RXYQ12P RXYQ12P RXYQ12P RXYQ12P RXYQ12P
Outdoor unit 2 RXYQ12P RXYQ12P RXYQ12P RXYQ12P RXYQ12P RXYQ16P RXYQ16P
Outdoor unit 3 RXYQ12P RXYQ12P RXYQ14P RXYQ16P RXYQ18P RXYQ16P RXYQ18P
Total number of connectable
indoor units
55 58 61 64
Total capacity of connectable
indoor units (kW)
47.50~123.50 50.25~130.65 53.50~139.10 56.00~145.60 58.00~150.80 61.75~160.55 63.75~165.75
HP 48HP 50HP
System name RXYQ48PH RXYQ50PH
Outdoor unit 1 RXYQ16P RXYQ16P
Outdoor unit 2 RXYQ16P RXYQ16P
Outdoor unit 3 RXYQ16P RXYQ18P
Total number of connectable
indoor units
64
Total capacity of connectable
indoor units (kW)
67.50~175.50 69.50~180.70
