Si34-601A Model Selection
General Information 7
4. Model Selection
VRV III Heat Pump Series
Connectable indoor units number and capacity
Normal Series
HP 5HP 8HP 10HP 12HP 14HP 16HP 18HP
System name RXYQ5P RXYQ8P RXYQ10P RXYQ12P RXYQ14P RXYQ16P RXYQ18P
Outdoor unit 1 RXYQ5P RXYQ8P RXYQ10P RXYQ12P RXYQ14P RXYQ16P RXYQ18P
Outdoor unit 2 – – – – – – –
Outdoor unit 3 – – – – – – –
Total number of connectable
indoor units
8 131619232629
Total capacity of connectable
indoor units (kW)
7.00~18.20 11.20~29.12 14.00~36.40 16.75~43.55 20.00~52.00 22.40~58.24 25.20~65.52
HP 20HP 22HP 24HP 26HP 28HP 30HP 32HP
System name RXYQ20P RXYQ22P RXYQ24P RXYQ26P RXYQ28P RXYQ30P RXYQ32P
Outdoor unit 1 RXYQ8P RXYQ10P RXYQ8P RXYQ8P RXYQ10P RXYQ12P RXYQ16P
Outdoor unit 2 RXYQ12P RXYQ12P RXYQ16P RXYQ18P RXYQ18P RXYQ18P RXYQ16P
Outdoor unit 3 – – – – – – –
Total number of connectable
indoor units
32 35 39 42 45 48 52
Total capacity of connectable
indoor units (kW)
27.95~72.67 30.75~79.95 33.60~87.36 36.40~94.64 39.15~101.79 41.95~109.07 44.70~116.22
HP 34HP 36HP 38HP 40HP 42HP 44HP 46HP
System name RXYQ34P RXYQ36P RXYQ38P RXYQ40P RXYQ42P RXYQ44P RXYQ46P
Outdoor unit 1 RXYQ16P RXYQ18P RXYQ8P RXYQ8P RXYQ8P RXYQ8P RXYQ10P
Outdoor unit 2 RXYQ18P RXYQ18P RXYQ12P RXYQ16P RXYQ16P RXYQ18P RXYQ18P
Outdoor unit 3 – – RXYQ18P RXYQ16P RXYQ18P RXYQ18P RXYQ18P
Total number of connectable
indoor units
55 58 61 64
Total capacity of connectable
indoor units (kW)
47.50~123.50 50.25~130.65 53.50~139.10 56.00~145.60 58.00~150.80 61.75~160.55 63.75~165.75
HP 48HP 50HP 52HP 54HP
System name RXYQ48P RXYQ50P RXYQ52P RXYQ54P
Outdoor unit 1 RXYQ12P RXYQ14P RXYQ16P RXYQ18P
Outdoor unit 2 RXYQ18P RXYQ18P RXYQ18P RXYQ18P
Outdoor unit 3 RXYQ18P RXYQ18P RXYQ18P RXYQ18P
Total number of connectable
indoor units
64
Total capacity of connectable
indoor units (kW)
67.50~175.50 69.50~180.70 71.50~185.90 73.50~191.10
