Si34-601A Combination of Outdoor Units
General Information 5
3. Combination of Outdoor Units
Normal Series
Note: For multiple connection of 18HP system or more, an optional Daikin Outdoor Unit Multi
Connection Piping Kit is required.
System
Capacity
Number
of units
Module
Outdoor Unit Multi Connection
Piping Kit (Option)
5 8 10 12 14 16 18
5HP 1
●
—
8HP 1
●
10HP 1
●
12HP 1
●
14HP 1
●
16HP 1
●
18HP 1
●
20HP 2
●●
Heat Pump: BHFP22P100
22HP 2
●●
24HP 2
●●
26HP 2
●●
28HP 2
●●
30HP 2
●●
32HP 2
●●
34HP 2
●●
36HP 2
●●
38HP 3
●● ●
Heat Pump: BHFP22P151
40HP 3
●●●
42HP 3
●●●
44HP 3
●●●
46HP 3
●●●
48HP 3
●●●
50HP 3
●●●
52HP 3
●●●
54HP 3
●●●
