Specifications Si34-601A
38 Specifications
600×600 Ceiling Mounted Cassette Type (Multi Flow)
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outside temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outside temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
★
3 Indoor temp. : 20°CDB / outside temp.: 7°CDB, 6°CWB / Equivalent piping length; 7.5m, level difference;
0m. (Heat pump only)
4 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
★
5 Anechoic chamber conversion value, measured under JISB8616 conditions. During actual operation,
these values are normally somewhat higher as a result of ambient conditions.
Model FXZQ40M7V1B FXZQ50M7V1B
★
1 Cooling Capacity (19.5°CWB)
kcal/h 4,000 5,000
Btu/h 15,900 19,900
kW 4.7 5.8
★
2 Cooling Capacity (19.0°CWB) kW 4.5 5.6
★
3 Heating Capacity
kcal/h 4,300 5,400
Btu/h 17,000 21,500
kW 5.0 6.3
Casing Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 260×575×575 260×575×575
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 2×10×1.5 2×10×1.5
Face Area m² 0.269 0.269
Fan
Model QTS32C15M QTS32C15M
Type Turbo Fan Turbo Fan
Motor Output × Number
of Units
W 55×1 55×1
Air Flow Rate (H/L)
m³/min 11/8 14/10
cfm 388/282 494/353
Drive Direct Drive Direct Drive
Temperature Control Microprocessor Thermostat for Cooling and Heating Microprocessor Thermostat for Cooling and Heating
Sound Absorbing Thermal Insulation Material Foamed Polystyrene/Foamed Polyethylene Foamed Polystyrene/Foamed Polyethylene
Piping
Connections
Liquid Pipes mm
φ
6.4 (Flare Connection)
φ
6.4 (Flare Connection)
Gas Pipes mm
φ
12.7 (Flare Connection)
φ
12.7 (Flare Connection)
Drain Pipe mm
VP20
External Dia. 26
Internal Dia. 20
VP20
External Dia. 26
Internal Dia. 20
Machine Weight (Mass) kg 18 18
★
5 Sound Level (H/L) (230V) dBA 36/28 41/33
Safety Devices Fuse Fuse
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve
Connectable outside unit R-410A M(A) Series R-410A M(A) Series
Decoration
Panels
(Option)
Model BYFQ60BW1 BYFQ60BW1
Panel Color White (Ral 9010) White (Ral 9010)
Dimensions: (H×W×D) mm 55×700×700 55×700×700
Air Filter
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Weight kg 2.7 2.7
Standard Accessories
Operation Manual, Installation Manual, Paper Pattern for
Installation, Drain Hose, Clamp Metal, Washer Fixing Plate,
Sealing Pads, Clamps, Screws, Washer for Hanging
Bracket, Insulation for Fitting.
Operation Manual, Installation Manual, Paper Pattern for
Installation, Drain Hose, Clamp Metal, Washer Fixing Plate,
Sealing Pads, Clamps, Screws, Washer for Hanging
Bracket, Insulation for Fitting.
Drawing No. 3D038929A
() ()
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
