Model Names of Indoor/Outdoor Units Si34-601A
2 General Information
1. Model Names of Indoor/Outdoor Units
Indoor Units
Note:FXDQ has following 2 Series, as show below.
FXDQ-P, N(A)VET: without Drain Pump (For General, Asia: except for EU, China and Australia)
FXDQ-P, N(A)VE: with Drain Pump
BEV unit is required for each indoor unit.
MA, NA: RoHS Directive models; Specifications, Dimensions and other functions are not changed compared
with M, N type.
Outdoor Units
Normal Series
High COP Series (Energy Saving Series)
Type Model Name Power Supply
Ceiling Mounted
Cassette Type
(Double Flow)
FXCQ 20M 25M 32M 40M 50M 63M 80M — 125M — —
VE
Ceiling Mounted
Cassette Type
(Multi Flow)
FXFQ — 25M 32M 40M 50M 63M 80M 100M 125M — —
600×600 Ceiling
Mounted Cassette
Type
FXZQ 20M 25M 32M 40M 50M — — — — — — V1
Ceiling Mounted
Cassette Corner Type
FXKQ — 25MA 32MA 40MA — 63MA — — — — —
VE
Slim Ceiling Mounted
Duct Type
FXDQ-
PVE
20P 25P 32P — — — — — — — —
FXDQ-
PVET
20P 25P 32P — — — — — — — —
FXDQ-
NAVE
20NA 25NA 32NA 40NA 50NA 63NA — — — — —
FXDQ-
NVET
20N 25N 32N 40N 50N 63N — — — — —
Ceiling Mounted
Built-In Type
FXSQ 20M 25M 32M 40M 50M 63M 80M 100M 125M — —
Ceiling Mounted
Duct Type
FXMQ — — — 40MA 50MA 63MA 80MA
100MA 125MA 200MA 250MA
Ceiling Suspended
Type
FXHQ — — 32MA — — 63MA —
100MA
———
Wall Mounted Type
FXAQ 20MA 25MA 32MA 40MA 50MA 63MA — — — — —
Floor Standing Type
FXLQ 20MA 25MA 32MA 40MA 50MA 63MA — — — — —
Concealed Floor
Standing Type
FXNQ 20MA 25MA 32MA 40MA 50MA 63MA — — — — —
Outdoor Air Processing
Unit
FXMQ-
MF
————————
125MF 200MF 250MF
V1
Ceiling Suspended
Cassette Type
FXUQ ——————71MA
100MA 125MA
——
Connection Unit
BEVQ-MA
——————71MA
100MA 125MA
—— VE
Series Model Name Power Supply
Heat Pump RXYQ
5P 8P 10P 12P 14P 16P 18P 20P 22P
Y1(E)24P 26P 28P 30P 32P 34P 36P 38P 40P
42P 44P 46P 48P 50P 52P 54P
Series Model Name Power Supply
Heat Pump RXYQ
16PH 18PH 24PH 26PH 28PH 30PH 32PH 34PH 36PH
Y1(E)
38PH 40PH 42PH 44PH 46PH 48PH 50PH
∗Power Supply VE: 1 phase 220~240V, 50Hz
V1: 1 phase 220~240V, 50Hz
Y1: 3 phase 380~415V, 50Hz
E: The unit with anti corrosion treatment
