Si34-601A Troubleshooting by Indication on the Remote Controller
Troubleshooting 245
Troubleshooting
Note: Refer check 1 and 2 to P.311.
Check 1
Check for the fan motor
connector (Power supply cable)
Check 2
Check for the fan motor
connector (Signal cable)
NO
NO
Resistance
of the U, V, and W
phases of the fan motor
has got imbalanced or short
circuits have been established
amoung the U, V,
and W
phases.
YES
Turn ON the power supply.
NO
Has a
short circuit been
established between
the fan motor signal cables
Vcc and GND, and UVW
and GND,
respectively?
YES
The LED
(HAP) on the
compressor inverter
PCB is blinking, but the LED
(HAP) on the fan inverter
PCB is not
blinking.
YES
Replace the outdoor unit fan
motor.
Replace the outdoor unit fan
motor.
Replace the fan inverter
PCB.
Replace the outdoor unit fan
motor.
(V3077)
