PLANET Mesh Network Manager Guide
PLANET Mesh Network Manager Guide
Page
121 of 126
5) Operational
• A checkbox to enable or disable the system to send the operational traps
6) Flash
• A checkbox to enable or disable the system to send the traps regarding Flash
7) TFTP
• A checkbox to enable or disable the system to send the traps regarding TFTP
8) Image
• A checkbox to enable or disable the system to send the trap regarding Image
9) Enable Trap on Authentication Failure
• A checkbox to enable or disable the trap on authentication failure
Parameters (SNMP Trap Table)
1) IP Address
• The destination IP Address of the trap receiver, to receive the trap
• Data type: IP Address
2) Community
• The community keyword of the SNMP Trap.
• Data type: Display String, default value is “public”
• MUST reenter the same community at the correspond Confirm field
3) Comment
• An optional comment regarding the table entry
• Data type: Display String
4) Active
• Define the status of the table entry, either active or inactive
