Icom IC-7200 [68/104] Frequency copying
![Icom IC-7200 [68/104] Frequency copying](/views2/1074133/page68/bg44.png)
63
■Frequency copying
The frequency and operating mode in a memory
channel can be copied to the VFO.
D Copying in memory mode
This is useful for copying a memory channel’s con-
tents (frequency and operating mode) to a VFO while
operating in memory mode.
This is useful when searching for signals around a
memory channel frequency.
NOTE: While operating in VFO mode, pushing and
holding
V/M
➔
for 1 sec. also copy the selected
memory channel’s contents (frequency and oper-
ating mode) to a VFO.
When you have changed the frequency or operat-
ing mode in the selected memory channel:
• Displayed frequency and mode are copied.
• Programmed frequency and mode in the mem-
ory channel are not copied, and they remain in
the memory channel.
q
Push
V/M
➔
to select memory mode.
w
Rotate [M-CH] to select the desired memory
channel to be copied.
• If the RIT control indicator lights orange, push
M-CH/RIT
SET
. (p. 61)
• Set the frequency or operating mode if required.
• “
” appears if the selected memory channel is a
blank channel (and does not have contents). In this
case copying is not possible.
Channel decreases
Channel increases
RIT control indicator
goes out
e Push and hold
V/M
➔
for 1 sec. to copy the fre-
quency and operating mode.
• 3 beeps are emitted when the copying is successful.
• Displayed frequency and operating mode are copied.
r To return to VFO mode, push
V/M
➔
.
• Copied frequency and operating mode appear in the
display.
You can return to VFO mode before copying
the frequency and operating mode in step e.
[EXAMPLE]: Copying contents of memory 16.
Operating frequency
Contents of memory 16
: 14.020 MHz/CW
: 14.018 MHz/CW
V/M
1
1.8
Push and hold for 1 sec.,
then push .
V/M
1
1.8
Rotate [M-CH]
7
MEMORY OPERATION
