Icom IC-7200 [75/104] General
![Icom IC-7200 [75/104] General](/views2/1074133/page75/bg4b.png)
10
70
SET MODE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
■ General
Set mode is used for programming infrequently
changed values or conditions of functions.
The IC-7200 has 2 separate set modes: quick set
mode and set mode.
SET
M-CH/RIT
SET
M-CH/RIT
SET
M-CH/RIT
Push and hold
for 1 sec.
Push
momentarily
Push
momentarily
Push and hold
for 1 sec.
Quick set mode Set mode
Normal operation mode
D Quick set mode operation
q Push and hold
M-CH/RIT
SET
for 1 sec. to enter the
quick set mode.
w Rotate [M-CH] to select the desired item.
e
Set the desired condition or value using [DIAL].
• Push and hold
M-CL
for 1 sec. to select the default
condition or value.
r Repeat w and e to set other items.
t
Push
M-CH/RIT
SET
to exit the quick set mode and re-
turn to normal operation.
[DIAL]
MODE
TUNER
TS
FILTER
SPCH
V/M
A/B
SPLIT
M-CL
SCAN
SET
ATT
P
.
AMP
COMP
VOX
MNF
RIT
1
2
3
4
5 6
7
8
0
50
28
1814
10
21
24
=
7
3.5
1.8
F-INP
M-CH/RIT
ENT
BAND
GENE
9
.
AGC
MW
ANF
METER
NR
NB
[M-CH]
D Set mode operation
q Push and hold
M-CH/RIT
SET
for 1 sec. to enter the
quick set mode.
w Repeat step q again to enter the set mode.
e Rotate [M-CH] to select the desired item.
r
Set the desired condition or value using [DIAL].
• Push and hold
M-CL
for 1 sec. to select the default
condition or value.
t Repeat e and r to set other items.
y
Push
M-CH/RIT
SET
to exit the set mode and return to
normal operation.
[DIAL]
MODE
TUNER
TS
FILTER
SPCH
V/M
A/B
SPLIT
M-CL
SCAN
SET
ATT
P
.
AMP
COMP
VOX
MNF
RIT
1
2
3
4
5 6
7
8
0
50
28
1814
10
21
24
=
7
3.5
1.8
F-INP
M-CH/RIT
ENT
BAND
GENE
9
.
AGC
MW
ANF
METER
NR
NB
[M-CH]
