![Icom IC-7200 [94/104] Command table](/views2/1074133/page94/bg5e.png)
D Command table
Command Sub command Description
00 — Send frequency data.
(for transceive operation)
01
00 Select LSB mode
(for transceive operation)
01 Select USB mode
(for transceive operation)
02 Select AM mode
(for transceive operation)
03 Select CW mode
(for transceive operation)
04 Select RTTY mode
(for transceive operation)
07 Select CW-R mode
(for transceive operation)
08 Select RTTY-R mode
(for transceive operation)
02
— Read band edge frequencies
03 — Read operating frequency
04 — Read operating mode
05 — Set operating frequency
06 00 Select LSB mode
01 Select USB mode
02 Select AM mode
03 Select CW mode
04 Select RTTY mode
07 Select CW-R mode
08 Select RTTY-R mode
07 — Select VFO mode
00 Select VFO A
01 Select VFO B
A0 Equalize VFO A and VFO B
B0 Exchange VFO A and VFO B
08 — Select memory mode
0001−0201*
Select memory channel
*P1=0200, P2=0201
09
— Memory write
0A — Memory to VFO
0B — Memory clear
0E 00 Scan stop
01 Programmed/memory scan start
02 Programmed scan start
22 Memory scan start
D0 Set scan resume OFF
D3 Set scan resume ON
0F 00 Turn the split function OFF
01 Turn the split function ON
10 00 Select 10 Hz (or 1 Hz) tuning step
01 Select 100 Hz tuning step
02 Select 1 kHz tuning step
03 Select 5 kHz tuning step
04 Select 9 kHz tuning step
05 Select 10 kHz tuning step
11 — Set/read attenuator.
(
0=OFF, 20=ON (20 dB))
13 00 Announce with voice synthesizer
01 ( 00=all data 01=frequency and
02 S-meter; 02=receive mode)
Command Sub command Description
14 01 [AF] level setting
(0=max. CCW to 255=max. CW)
02 [RF] level setting
(0=max. CCW to 255=11 o'clock)
03 [SQL] level setting
(0=11 o'clock to 255=max. CW)
06 NR level setting
(0=0% to 255=100%)
07 Inside [PBT] setting (0= max. CCW,
128=center, 255=max. CW)
08 Outside [PBT] setting (0= max.
CCW, 128=center, 255=max. CW)
09 CW Pitch setting (0=300 Hz to
255=900 Hz (5 Hz steps))
0A RF power setting
(0=minimum to 255=100%)
0B MIC gain setting
(0=0% to 255=100%)
0C Key speed level setting
(0=6 wpm to 255=60 wpm)
0D [MNF] setting (0=max. CCW,
128=center, 255=max. CW)
0E COMP level setting
(0=0 to 255=10)
0F Break-IN delay setting
(0=2.0 d to 255=13.0 d)
12 NB level setting
(0=0% to 255=100%)
16 VOX gain setting
(0=0% to 255=100%)
17 Anti VOX gain setting
(0=0% to 255=100%)
15 01 Read squelch condition
02 Read S-meter level
11 Read RF power meter
12 Read SWR meter
13 Read ALC meter
16 02 Preamp (0=OFF, 1=ON)
12 AGC selection
(0=OFF, 1=Fast, 2=Slow.)
22 Noise blanker (0=OFF, 1=ON)
40 Noise reduction (0=OFF, 1=ON)
41 Auto notch (0=OFF, 1=ON)
44 Speech compressor
(0=OFF, 1=ON)
46 VOX function (0=OFF, 1=ON)
47 Break-IN function (0=OFF, 1=semi
BK-IN, 2=full BK-IN)
48 Manual notch (0=OFF, 1=ON)
4F Twin peak filter (0=OFF, 1=ON)
50 Dial lock function (0=OFF, 1=ON)
19 00 Read the transceiver ID
1A 00 Set/read memory contents
An additional code, 0001−0201
(0200=P1, 0201=P2), must be added
to specify the memory channel.
01 Set/read band stacking register
contents (see p. 91 for details)
02 Set/read the selected filter width
( SSB, CW, RTTY: 0=50 Hz
to 40/31=3600/2700 Hz;
AM:
0=200 Hz to 39=8 kHz)
0301 Set/read RF power setting
(0=minimum to 255=100%)
0302 Set/read MIC gain setting
(0=0% to 255=100%)
