3
2
PANEL DESCRIPTION
New2001
e UP AND DOWN KEYS [∫]/[√]
<Common>
➥ While in the Menu mode, push to select a menu item.
(pp. 9, 28)
➥ Push to select a voice channel in the voice channel se-
lection screen.
(p. 21)
<In the plotter display>
Push to select the display range.
(p. 15)
<In the target or danger list display>
Push to select an AIS target in the target or danger list
display.
(pp. 16, 17)
r ENTER KEY [ENT]
<Common>
➥ Push to display the detail screen of the selected AIS
target.(pp.15−17)
➥ Push to save the input data. (pp. 8, 10, 15)
➥ Push to enter the Menu item setting mode.
(pp. 9, 28)
➥ While in the Menu item setting mode, push to select a
menu option.
(pp. 11, 12, 16, 29, 32
−34
)
➥ While searching for a GPS satellite, push [ENT] to dis-
playtheGPSinformationscreen.(p.14,31)
t MENU KEY [MENU]
<Common>
➥ Push to enter the Menu mode. (pp. 9, 28)
➥ While in the Menu mode, push to exit it, and return to
the plotter, target list or danger list display which was
selected before you entered the Menu mode.
y CLEAR KEY [CLEAR]
<Common>
➥ Push to cancel the entered function, or return to the pre-
vious screen. (pp. 10, 13, 23)
➥ While in the Menu mode, push to exit it, and return to the
previous screen. (pp. 9, 28)
➥Pushtostopanalarm.(pp.15−17)
u DSC KEY [DSC]
<Common>
➥ When the AIS target is selected, or the detail screen is
displayed, push to display the voice channel selection
screen. (p. 22)
➥ After selecting the voice channel, push to transmit an
Individual DSC call to the selected AIS target. (p. 22)
This function is available only when a transceiver is con-
nected to the transponder. (p. 39)
i POWER/BRILL KEY [POWER•BRILL]
<Common>
➥
Hold down for 1 second to turn the power ON or OFF.
(p.14)
•
After turning ON the power, the opening screen will appear.
➥ Push to show the display backlight and contrast adjust-
ing screen. (p. 15)
o MAN OVERBOAT KEY [MOB]
<Common>
Hold down for 1 second to set the waypoint.
(p. 25)
•TheMOBalarmsounds,andaagiconappearsonyourcurrent
position.
