MENU MODE OPERATION

■ General

q Push [MENU] to enter the Menu mode.

Push [∫] or [√] to select the desired item, then push [ENT].

e Select the desired option or check the screen contents.

 Theproceduresaredescribedonpages29to34.

 •Someitemsare not described in this section. See the list to the

right for the speciﬁed pages.

r Repeat steps w and e to select or check other items.

t Push [CLEAR] to exit the Menu mode.

[CLEAR]

[ENT]

[MENU]

[∫]

[√]

■ Menu mode items

The Menu mode contains the following items.

Item Ref. Item Ref.

North up/COG up* p. 16 User Setting

CPA/TCPA  •RCVMSGBUZZ p. 33

 •Alarm p. 29  •InternalGPS p. 33

 •SlowWarn p. 29 - SBAS Function p.34

 •CPA,TCPA p. 30 - SBAS Search p.34

Message - SBAS Satelite p.34

 •RXLog* p. 23 Initial Setting

Waypoint  •SetMMSI* pp. 7, 9

 •List* p.24  •SetName*

pp. 9, 13

 •Add* p.24  •SetCallSign*

pp. 9, 13

 •Edit* p. 26  •SetINTGPSPOS* p. 10

 •Delete* p. 27  •

Set EXT GPS POS

* p. 10

Own Static p. 30  •SetTypeofShip* p. 10

Own Dynamic p. 31  •SetInput/Output* p. 11

GPS Information p. 31 Channel Information p.34

Alarm Status p. 32 Diagnostics

User Setting  •MonitorTest* p.44

 •KeyBeep p. 32  •TransponderTest* p.45

 •AlarmBuzzer p. 33  •VersionInformation* p.45

*These items are not described in this section. See the speciﬁed page.
