17
4
BASIC OPERATION
New2001
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
■ Danger list display operation
The danger list display shows any dangerous target whose
CPA (Closest Point of Approach) distance is less than 6 nm
(nautical miles), and TCPA (Time to CPA) time is less than 60
minutes to your vessel.
The dangerous target data is sorted by CPA or TCPA (you
can choose either; see step q).
Their CPA and TCPA information is automatically updated
every 5 seconds, then the dangerous target data is sorted.
qPush [DISP MODE] several times to select the danger list
display.
•Push [Ω] to sort the AIS target data by CPA.
•Push [≈] to sort the AIS target data by TCPA.
w Push [∫] or [√] to select the desired AIS target.
e Push [ENT] to display it’s detail screen. (See to the right)
NOTE: The alarm buzzer sounds when a malfunction oc-
curs or an AIS target is closer than your CPA and TCPA
settings,dependingonthepresetting.(pp.29,30,33,44)
➥ To stop the alarm buzzer, push [CLEAR].
•Ifthepopupscreenisdisplayed,push[CLEAR] again to turn
it OFF.
■ About the detail screen
The detail screen shows information about the selected AIS
target. The contents differ, depending on the AIS class.
In the detail screen, pushing [CLEAR] returns to the previ-
ous screen, which was displayed before entering the details
screen.
See pages 18 to 21 for the detail screen of each AIS class.
