33
7
CALL CHANNEL OPERATION
■
Programming the call channel
In addition to an operating frequency, duplex information, sub-
audible tone information (tone encoder or tone squelch
ON/OFF and its frequency) and an alphanumeric name can
be programmed into the call channel.
➀ Push [M/CALL] one or twice to display a large “C” in the
memory channel readout.
➁ Set the desired frequency in VFO mode:
➥ Push [VFO] to select VFO mode.
➥ Set the frequency using the tuning dial.
➥ Set other data as desired.
➂ Push [(S.MW)MW] for 1 sec. to program.
[EXAMPLE]: Programming 145.120 MHz into the call channel via the microphone.
✔CONVENIENT
The call channel can also be programmed from the VFO di-
rectly (similar to memory programming).
Ä Push [
(MR)CALL] for 1 sec. to select the call
channel.
Å Set the desired frequency in VFO mode:
➥ Push [VFO] to select VFO mode.
➥ Push the desired frequency using the key-
pad.
➥ Set other data as desired.
Ç Push [FUNC], then [EMW] for 1 sec. to pro-
gram.
MW
A
X
9
5
1
9
5
1
VFO
2
SCAN
0
5
MID
1
MONI
1
MONI
4
HIGH
C
ENT
MW
FUNC
A
CLR
CALL
MR
Call channel VFO mode then
for 1 sec.
for 1 sec.
Beep
Beep
Beep
“
“
“
“
“
9
5
1
9
5
1
