54
13 WIRELESS OPERATION
■ Microphone
address
The transceiver has 8 possible microphone addresses (in-
cluding OFF) to help prevent interference from other HM-90
wireless microphones. Set both the microphone address and
microphone dip switch to the same value as follows.
☞ NOTE: When the supplied microphone is connected, the
transceiver rejects control signals from the HM-90 even
when the microphone address is matched.
D Microphone address
➀ Push [PWR] to turn power OFF.
➁ While pushing [SET], turn power ON to enter initial set
mode.
➂ Push [SET] one or more
times to select the “ADR”
display as shown at right.
➃ Rotate the tuning dial to set
the microphone address to
0–7 or to turn the microphone control OFF.
• When “ADR--OF” is selected, the transceiver rejects all control
signals from the HM-90.
➄ Push [PWR] to turn power OFF and exit initial set mode.
USING
INITIAL SET MODE
The display shows the address
is set to 2.
D Microphone dip switch
➀ Remove the switch cover from the microphone rear panel.
➁ Set the microphone dip switch and the microphone ad-
dress to the same value as shown below.
➂ Replace the switch cover.
MICROPHONE DIP SWITCH
ADDRESS S1-1 S1-2 S1-3
ADR-0 OFF OFF OFF
ADR-1 (default) ON OFF OFF
ADR-2 OFF ON OFF
ADR-3 ON ON OFF
ADR-4 OFF OFF ON
ADR-5 ON OFF ON
ADR-6 OFF ON ON
ADR-7 ON ON ON
LOCK
AFC AFC-OFF PTT-M MW
PGR
CALL
123A
456B
MR VFO CLR
C-SQL DTMF D-OFF
HIGH MID LOW SET
Dip switch
ON
OFF
1 2 3
(S1)
Switch cover
