Icom IC-2100H [46/72] Priority watch
![Icom IC-2100H [46/72] Priority watch](/views2/1074419/page46/bg2e.png)
42
10
PRIORITY WATCH
■ Priority watch types
Priority watch checks for signals on a memory or call chan-
nel every 5 sec. while operating on a VFO frequency. The
transceiver has 3 priority watch types to suit your needs. You
can transmit on the VFO frequency while the priority watch
operates.
The watch resumes according to the selected scan resume
condition. See previous page for details.
☞ NOTES:
➧ Priority watch cannot be started from a scratch pad mem-
ory.
➧ If the DTMF memory encoder is activated, it is automati-
cally cancelled when priority watch starts.
➧ If the pocket beep function is activated, the transceiver
automatically selects the tone squelch function when pri-
ority watch starts.
➧ When “SCT-EP” is selected for the scan resume condi-
tion, the priority watch pauses on a no-signal channel.
(p. 41)
MEMORY CHANNEL
WATCH
While operating on a VFO
frequency, priority watch
checks for a signal on the
selected memory channel
every 5 sec.
• Amemory channel with skip in-
formation can be watched.
MEMORY SCAN
WATCH
While operating on a VFO
frequency, priority watch
checks for signals on each
memory channel in se-
quence.
• The memory skip function is
useful to speed up the scan.
CALL CHANNEL
WATCH
While operating on a VFO
frequency, priority watch
checks for a signal on the
call channel every 5 sec.
VFO
frequency
Memory
channel
5 sec.
125 msec.
VFO
frequency
Mch 2
Mch 1
Mch 3
Mch 100
5 sec.
125 msec.
SKIP
VFO
frequency
Call
channel
5 sec.
125 msec.
