Icom IC-2100H [47/72] I priority watch operation
![Icom IC-2100H [47/72] I priority watch operation](/views2/1074419/page47/bg2f.png)
43
10
PRIORITY WATCH
■ Priority watch operation
➀ Select VFO mode; then, set an operating frequency.
➁ Set the watching channel(s).
For memory channel watch:
Select the desired memory channel.
For memory scan watch:
Select memory mode; then, push [
(V/MHz)SCAN] for 1 sec.
to start memory scan.
For call channel watch:
Select the call channel by pushing [M/CALL] once or twice.
➂ Push [(M/CALL)PRIO] for 1 sec. to start the watch.
• The transceiver checks the memory or call channel frequency
every 5 sec.
• The watch resumes according to the selected scan resume con-
dition. (p. 41)
• While the watch is pausing, pushing [M/CALL] resumes the
watch manually.
➃ Push [M/CALL] while the display shows the VFO frequency
to stop the watch.
PRIO
M
9
5
1
While pausing on the
memory or call channel
“PRIO” flashes.
Ä Select VFO mode; then, set an operating fre-
quency.
Å Set the watching channel(s).
For memory channel watch:
Push [MR] then [Y] or [Z] to select the desired
memory channel.
For memory scan watch:
Push [MR] then [➁SCAN] to start the memory
scan.
For call channel watch:
Push and hold [
(MR)CALL] to select the call
channel.
Ç Push [➂PRIO] to start the watch.
• The transceiver checks the memory or call channel
frequency every 5 sec.
• The watch resumes according to the selected scan
resume condition. (p. 41)
• To resume the watch manually when paused, push
[➂PRIO] or [ECLR].
É To stop the watch, push [ECLR] once (or twice
while watch is paused).
PRIO
3
