40
9
SCAN OPERATION
■ Skip channel
setting
The memory skip function speeds up scanning by checking
only those memory channels not set as skip channels. Set
skip channels as follows.
➀ Select a memory channel:
➥ Select memory mode by pushing [M/CALL] once or
twice.
➥ Rotate the tuning dial to select the memory channel.
➁ Push [SET] one or more times until “CHS” appears as
shown above.
➂ Rotate the tuning dial to turn the skip function ON or OFF
for the selected channel.
•“~” appears : The memory channel is skipped during
(CHS-ON) memory scan.
•“~” disappears : The memory channel is scanned during
(CHS-OFF) memory scan.
➃ Push [V/MHz] to exit set mode.
USING
SET MODE
The display shows that
memory channel 10 is set
as a skip channel.
M
X
SKIP
9
5
1
Ä Select a memory channel.
➥ Select memory mode by pushing [MR].
➥ Push [Y] or [Z] to select a memory channel.
Å Push [FSET] one or more times until “CHS” ap-
pears as shown at left.
Ç Push [Y] or [Z] to set or cancel the skip setting.
• See item ➂ at left for skip indicator details.
É Push [ECLR] to exit set mode.
☞ NOTES:
Even though scan edge channels cannot be set as skip
channels, they ARE skipped during memory scan.
Memory channels programmed with memory names can-
not be set as skip channels. To set them as skip channels,
first push and hold [ANM] for 1 sec., then set as described
above.
SET
B
