Icom IC-2100H [50/72] Pocket beep and tone squelch
![Icom IC-2100H [50/72] Pocket beep and tone squelch](/views2/1074419/page50/bg32.png)
46
12
POCKET BEEP AND TONE SQUELCH
■ Pocket beep operation
This function uses subaudible tones for calling and can be
used as a “common pager” to inform you that someone has
called while you were away from the transceiver.
D Waiting for a call from a specific station
➀ Set the operating frequency.
➁ Program the subaudible tone frequency in set mode.
• See p. 23 for programming details.
➂ Push [TONE] one or more times to indicate “T SQLS”
in the function display.
➃ When a signal with the correct tone is received, the trans-
ceiver emits beep tones and flashes “S”.
• Beep tones sound for 30 sec and “S” flashes. To stop the
beeps and flashing manually, push any key. When the beep
tones are not stopped manually, “S ” continues flashing until
step ➄.
➄ Push [PTT] to answer.
➅ Push [TONE] once or twice to cancel the function.
Ä Set the operating frequency.
Å Program the subaudible tone frequency in set
mode.
• See p. 23 for programming details.
Ç Push [FUNC] then [➇T SQLS] to turn the
pocket beep ON.
É When a signal with the correct tone is received,
the transceiver emits beep tones for 30 sec. and
flashes “S”.
Ñ Push [PTT] to answer or push [ECLR] to stop
the beeps and flashing.
• Tone squelch is automatically selected.
• Pushing [FUNC] then [➈TSQL] also selects the tone
squelch.
Ö To cancel the function, push [FUNC] then [GT-
OFF].
D Calling a waiting station using pocket beep
A subaudible tone matched with the station’s frequency is
necessary. Use the tone squelch on the next page or a sub-
audible tone encoder (pgs. 23, 47)
T SQLS
8
T-OFF
C
