Icom IC-2100H [51/72] I tone squelch operation
![Icom IC-2100H [51/72] I tone squelch operation](/views2/1074419/page51/bg33.png)
47
12
POCKET BEEP AND TONE SQUELCH
■ Tone squelch operation
The tone squelch opens only when receiving a signal with the
same pre-programmed subaudible tone.
➀ Set the operating frequency.
➁ Program the subaudible tone frequency in set mode.
• See p. 23 for programming details.
➂ Push [TONE] one or more times to indicate “T SQL” ap-
pears in the function display.
➃ When a signal with the correct tone is received, the
squelch opens and the signal can be heard.
• When the received signal includes an unmatched tone, the
squelch does not open. However, the S/RF indicator shows the
received signal strength.
• To open the squelch manually, push [MONI].
➄ Operate the transceiver in the normal way (push [PTT] to
transmit; release [PTT] to receive).
➅ To cancel the tone squelch, push [TONE].
•“T SQL” disappears from the function display.
Ä Set the operating frequency.
Å Program the subaudible tone frequency in set
mode.
• See p. 23 for programming details.
Ç Push [FUNC] then [➈T SQL] to turn the tone
squelch ON.
É When a signal with the correct tone is received,
the squelch opens and the signal can be heard.
• When the received signal includes an incorrect tone,
the squelch does not open. However, the S/RF indi-
cator shows the received signal strength.
• To open the squelch manually, push [➀MONI].
Ñ Operate the transceiver in the normal way (push
[PTT] to transmit; release [PTT] to receive.
Ö To cancel the tone squelch, push [FUNC] then
[GT-OFF].
T SQL
9
T-OFF
C
