Chapter 2. Hardware Setup

Installing the RS-232 Controller

In order to use the RS-232 serial interface to attach a high-end controller (such

as a PC) to the VM0202H / VM0202HB, use a serial cable such as a modem

cable. The end connecting to the VM0202H / VM0202HB should have a 9-pin

male connector. Connect this to the serial interface on the rear of the VM0202H

/ VM0202HB.

For VM0202H installation, refer to step 1 from the installation diagram on

page 13.

For VM0202HB installation, refer to step 7 from the installation diagram on

page 14.

Note: To configure the controller serial port, see page 21.
