Aten SN3402 [17/111] Top view

Chapter 1. Introduction

Top View

4 power jack Connects the Secure Device Server to power using a power

adapter.

No. Component Description

1 grounding

terminal

Grounds the unit by connecting to a suitable grounded

object using a grounding wire.

2 serial port 1

LED

Lights green or orange when data is being sent or received

via the unit’s RS-232 serial port 1.

3 serial port 2

LED

Lights green or orange when data is being sent or received

via the unit’s RS-232 serial port 2. (SN3002 / SN3002P

only)

4 status LED Lights or blinks yellow/green respectively for normal

operation or startup, and lights red when an error (i.e.

hardware failure and DHCP irregularity) occurs.

5 power LED Lights green when the Secure Device Server is powered

and ready.

421 53
