Aten SN3402 [24/111] Rack mount

Secure Device Server User Manual

Rack Mount

The Rack Mount Kit (VE-RMK1U) is required for mounting the Secure

Device Server onto a rack, as instructed below:

1. Place the device onto the mounting plate while latching one of its rack ears

onto the plate’s protruded dot, as illustrated below.

2. Secure the device to the mounting plate using the hexagon head screw

supplied. Users can secure the Secure Device Server either with its serial

port(s) facing inward or outward.

Mounting Plate

Protruded dot
