Aten SN3402 [55/111] Security level

Chapter 4. Web Console

SNMP

Note: Before SNMP can be used, make sure to Enable SNMP Agent service

in System > Security > Security Level.

Item Description

Send SNMP traps Check to enable SNMP service for sending SNMP trap event

notifications, as specified by the Advanced tab (see page 45).

SNMP v1 and v2c are supported.

IP/Server Address Enter the IP/server address to receive the SNMP trap events.

Port Enter the service port of the server to receive SNMP trap

events.

Community Enter the SNMP community.

SNMP Agent Enter the service port and community for an SNMP agent.
