Aten SN3402 [79/111] Sn3401 sn3401p sn3402 sn3402p as a modbus master which supports communication from up to 32 servers at the same time

Chapter 6. Port Operating Modes

SN3401 / SN3401P / SN3402 / SN3402P as a Modbus master, which

supports communication from up to 32 servers at the same time.

NetworkControl

SN3402P

Modbus Gateway

Power Meter as Modbus

RTU/ASCII Slave

Application Server as Modbus

TCP Master (e.g. SCADA)

RS-232/422/485

SN3402P

Modbus Gateway

HMI as Modbus

RTU/ASCII Master

DCS or PLC as

Modbus TCP Slave

RS-232

Network
