Secure Device Server User Manual

3. :Select the Secure Device Server in the Device List.

Note: 1. If the list is empty, or your device doesn't appear, double-check

that you have the correct network adapter selected and click

Enumerate to refresh the Device List.

2. If there is more than one device in the list, use the MAC address

to distinguish your device. The Secure Device Server’s MAC

address is located on its bottom panel.

4. To check the IP address of the Secure Device Server or set an IP address

for it, respectively select Obtain an IP address automatically or Use the

following IP address.

 For setting an IP address, fill in the required IP address, subnet mask

and gateway information according to your network environment.

5. Click Set IP. The IP address of the Secure Device Server is displayed in

the Device List.

6. Click Exit to close the program.

Without IP Installer (non-DHCP only)

On a non-Windows system, under non-DHCP network, users can assign a static

IP address to the Secure Device Server, different from its default of

192.168.0.60, by following the steps below.

1. Set your PC’s IP address to 192.168.0.XXX, where XXX can be any

number except for 10.

2. Type the device’s default IP address — 192.168.0.60 — in your browser’s

URL location bar.

3. Log in with a valid username and password (see page 21).

4. On the Secure Device Server’s web interface, assign a fixed IP address for

it according to your network environment.

5. Save the settings and log out. After you log out, make sure to reset your

PC’s IP address to its original value.
