Aten SN3402 [45/111] Serial tunneling client

Chapter 4. Web Console

 Serial Tunneling Server

 Serial Tunneling Client

Item Description

TCP port Sets the TCP/IP port value of the serial port operating as a

serial tunneling server.

Secure transfer Check to encrypt all data being transferred through the serial

COM ports between two Secure Device Server via Serial

Tunneling Server-Client., using SSL.

Item Description

Destination Enter the IP address and port value of the serial tunneling

server for sending data to.

Secure transfer Check to encrypt all data being transferred through the serial

COM ports between two Secure Device Servers via Serial

Tunneling Client-Server, using SSL.
