![Aten SN3402 [67/111] User management](/views2/1978162/page67/bg43.png)
55
Chapter 5
User Management
Overview
This chapter takes users through how to add or edit the login accounts of Secure
Device Server, including the administrator, as well as using third-party
authentication services.
User
The Secure Device Server supports up to 16 user accounts, with two types of
users, as described below:
User Type Role
Administrator Able to access and configure all serial ports, and manage
other login accounts
User Only able to access and/or configure the authorized serial
ports, as permitted by the administrator, and unable to
configure any of the device’s system settings.
Item Description
Name Displays the username of the user account.
Type Displays the account type, Administrator or User.
Description Additional information used to describe the user account.
Status Displays the status of the user account, which includes:
Normal: The account functions normally.
Password Expired: The account’s password has expired
and must be changed.
