Chapter 4. Web Console
41
Time
The Time tab contains the time settings of the Secure Device Server, as
described in the table below.
Item Description
Time zone Select one of the following to set the time of the Secure Device
Server.
Synchronize with computer time: Synchronizes with the
time of the client PC.
Set manually: Manually set a desired time for the device.
Synchronize with NTP Server: Synchronizes the time of
the device to an NTP server.
Note:
If you use Synchronize with computer time or Set
manually, the time settings must be reconfigured
whenever the Secure Device Server is restarted.
It is recommended to use the Synchronize with NTP
Server setting to avoid time discrepancies especially
when the Secure Device Server has operated for a
while.
