Secure Device Server User Manual

 Modbus RTU/ASCII Slave

Select this option to set the Secure Device Server as an RTU/ASCII slave

device. An RTU/ASCII slave device can receive requests from up to 16

master devices.

Note:

 This mode is only applicable to SN3401 / SN3401P / SN3402 /

SN3402P.

 For SN3402 / SN3402P, the selected operation mode will be applied to

both serial ports on the unit.

 Disable

Select to disable the use of the serial port.
