Chapter 7. Port Access
73
Category Description
Font Configures the SNViewer’s font settings, including the font type, size,
and style. An example of the setting is displayed on the right.
Color Changes the Foreground, Background, Cursor Text, and/or Cursor
colors.
Use the HSL, Swatches, and HSV tabs to make detailed adjustments
and select the colors.
Below the tab is a Preview of how the color changes will look like.
Click OK to save the changes; Cancel to remove the changes and
exit; or Reset to revert to default color settings.
Size The size of the window determines the amount of information
displayed. Change the SNViewer’s window size by configuring the
Column and Row sizes.
Others Use this section to set the following:
Implicit CR in every LF: Checking this box adds an extra Carriage
Return when the [Enter] key is used, so the cursor returns aligned
on the left margin. Use this function if the text is not lining up on
the left margin after you hit [Enter].
Backspace is Delete Key
Local echo: An echo is a response from the serial device of
character(s) that have been inputted.
Auto: Characters that are typed in are echoed but not
displayed on the screen.
Force On: Characters that are typed in are echoed and
displayed on the screen as they are entered. Passwords are
displayed when enabled.
Force Off: Characters are not echoed from the serial device.
Buffer Size: This is the maximum size of the Log file.
Log File: The log file generates a log of characters sent from the
connected serial device to the SNViewer. The log must first be
created as a text file using an external editor such as Note or
Microsoft Word, then opened here. Next, you must enable Logging
on from the SNViewer Control Panel (see Control Panel
Functions, page 71).
