11500/ Translation of the original instructions

IMPORTANT: Always carry out the following operations with the machine in horizontal position. All oil

changes must be made when the machine is warm to facilitate the complete drainage of all the old oil.

Do not unscrew the oil cap when the engine is running, as this would cause the loss of the oil in the

circuit.

ENGINE OIL

Follow the instructions in the engine handbook carefully.

The oil level must be checked every 4 working hours and the oil changed every 50 hours approximately.

AIR FILTER

Check that the air filter is clean every 8 hours and even more often if working in very dusty conditions. In

the versions with dry air filter (fig. 5) check that the filter is clean. Attention: if the filter is blocked, do not

blow the cartridge with compressed air, but replace it. In the oil bath version (fig. 6), check that the filter

is clean and the oil is at the right level. Use the same oil as for the engine.

GEARBOX OIL

Check the level every 50 working hours approximately and if necessary, add 85W90 gearbox oil.

Change the oil once a year (quantity 1.350 kg).

To drain the old oil out of the gearbox casing, unscrew the screws on the cover around the tiller shaft

(fig. 1A no. 8).

TINE SHAFT

Remove the dust guards periodically (fib. 1A no. 8), clean the underlying area thoroughly, then replace.

USEFUL HINTS FOR PROPER USE

- Never leave the machine out in the rain.

- Never force the gearbox if the gear does not engage; give light touches on the clutch when

changing.

- Remove grass and leaves that may be deposited around the recoil starter.

- Under no circumstances must the machine be used without safety devices.

END OF SEASON MAINTENANCE

- Clean the machine carefully.

- Change engine and gearbox oil.

- Check and clean the air filter.

- Sharpen the tines and replace them if worn.

- Grease the accelerator and the clutch cables.

- If the machine operates intensively in dry and dusty environment, clean the cylinder cooling fins

(see engine handbook).
