12 English
Danger
Risk of accident while working on the unit.
During all tasks
Î Switch off the immersion pump in the
building.
– Operator
Work designated with the sign “Opera-
tor” may only be carried out by persons
who have been instructed in the safe
operation and maintenance on the wash
plant
– Customer Service
Work designated with the sign “Custom-
er Service” may only be done by the fit-
ters of Kärcher Customer Service or
fitters who have been authorised by
Kärcher.
Order No. 5.033-239.0
Order No. 2.641-521.0
Manual switching between processed/
fresh water for using fresh water in the high-
pressure cleaner (for e.g. for rinsing).
Notice
The equipment may only be installed by an
– mechanic of Kärcher
– or an from Kärcher authorized individual
The following requirements are necessary
in order to install the equipment:
– frost-free room with adequate ventila-
tion and exhausts
– Floor path for collecting sludge
– Strong wall for fastening the system
Unpack the equpiment and dispose of the
packing material properly.
The water installation depends on the spe-
cific conditions of the existing plant compo-
nents such as
– Type and model of high-pressure clean-
er or washing system
Note
The processed water outlet of the system is
directly connected to the water inlet of the
high-pressure cleaner. This can lead to
foam formation in the swimmer tank in high-
pressure cleaners with a swimmer tank. In
such a case, the high-pressure cleaner
must be switched to suction operatioins
(see separate operating instructions of the
high-pressure cleaner).
– Type and models of building-side com-
ponents (sludge collector, pump basin,
etc.)
– Nominal widtht, lengths and type of
channels
Hence, the water installation must be done
according to the specific local conditions.
The immersion pump specifications in the
building must meet the requirements out-
line in the "Technical Data / Immersion
Pump Requirements" section.
Danger
Risk of injury on account of tripping and fall-
ing.
Lay the hoses of the plant in such a way
that they do not pose a risk for tripping and
falling.
Troubleshooting
Who may remedy faults?
Fault Possible cause Remedy By whom
Plant out of order Power supply to the pump in the building is
interrupted.
Check power supply and ensure proper supply. Operator
Processed water is
coloured or is foam-
ing too much
Filter pre-tension is not correct. Adjust the filter pre-tension Operator
Filter inlay is defective (leaky) Replacing filter inlay Operator, Cus-
tomer Service
Sludge collector or pump basin is dirty Emptying and cleaning the basins Operator/ Dis-
posal agency
Improper detergents are used in the wash-
ing unit or washing hall
Use compatible detergents; rinse the system, if
necessary
Operator, Cus-
tomer Service
Detergent dosing in the washing unit is too
high
Check detergent dosing; reset, if necessary Operator, Cus-
tomer Service
Washing place cleaned with incompatible
detergents
Replace water and rinse the basins Operator
Filter output is too
low
Filament filter is blocked Backwash filament filter; replace filter inlay if re-
quired.
Operator
Immersion pump is of lesser dimension Install a suitable immersion pump (see require-
ments under "Technical Data")
Operator
Immersion pump is blocked, defective Clean, repair, replace immersion pump Operator, Cus-
tomer Service
Pipe or valve is leaky, defective, blocked Check pipes and valves; clean, repair or replace
as required
Operator, Cus-
tomer Service
Accessories
Filter inlay
Attachment set 'Fresh water switching'
Installing the unit (only for
experts)
Preparing the installation place
Unpack the equipment
Water installation
