Suzuki GSX-R1000 (2007) [17/549] Spark plug

PERIODIC MAINTENANCE 2-5

SPARK PLUG

SPARK PLUG AND IGNITION COIL/PLUG CAP REMOVAL

• Lift and support the fuel tank. (5-3)

• Remove the air cleaner box. (5-14)

• Disconnect all lead wire couplers from the ignition coil/plug

caps.



• Remove the ignition coils/plug caps.



• Remove the spark plugs.

\ 09930-10121: Spark plug wrench set

HEAT RANGE

• Check spark plug heat range by observing electrode color. If

the electrode of the spark plug is wet appearing or dark color,

replace the spark plug with hotter type one. If it is white or

glazed appearing, replace the spark plug with colder type

one.

Inspect every 6 000 km (4 000 miles, 12 months).

Replace every 12 000 km (7 500 miles, 24 months).

Disconnect the lead wire coupler before removing the

ignition coil/plug cap to avoid lead wire coupler dam-

age.

* Do not pry up the ignition coil/plug cap with a screw

driver or a bar to avoid its damage.

* Be careful not to drop the ignition coil/plug cap to

prevent short/open circuit.

Hot type Standard Cold type

NGK CR8EIA-9 CR9EIA-9 CR10EIA-9

ND IU24D IU27D IU31D
