Suzuki GSX-R1000 (2007) [528/549] Cylinder piston piston ring

10-50 SERVICING INFORMATION

CYLINDER + PISTON + PISTON RING Unit: mm (in)

ITEM STANDARD LIMIT

Compression pressure 1 300 – 1 700 kPa

(13 – 17 kgf/cm², 185 – 242 psi)

1 000 kPa

(10 kgf/cm

, 142 psi)

Compression pressure difference

—

200 kPa

(2 kgf/cm

, 28 psi)

Piston to cylinder clearance 0.035 – 0.045

(0.0014 – 0.0018)

0.120

(0.0047)

Cylinder bore 73.400 – 73.415

(2.8900 – 2.8903)

Nicks or

Scratches

Piston diam. 73.360 – 73.375

(2.8882 – 2.8888)

Measure at 10 mm (0.39 in) from the skirt end.

73.280

(2.8850)

Cylinder distortion

—

0.02

(0.008)

Piston ring free end gap

1st Approx. 6.5 (0.26)

5.2

(0.20)

2nd T Approx. 8.0 (0.31)

6.4

(0.25)

Piston ring end gap

1st

0.06 – 0.18

(0.002 – 0.007)

0.50

(0.020)

2nd T

0.06 – 0.18

(0.002 – 0.007)

0.50

(0.020)

Piston ring to groove clearance

1st —

0.180

(0.0071)

2nd —

0.150

(0.0059)

Piston ring groove width

1st

0.83 – 0.85 (0.0327 – 0.0335)

1.30 – 1.32 (0.0512 – 0.0520)

—

2nd

0.81 – 0.83

(0.0319 – 0.0327)

—

Oil

1.51 – 1.53

(0.0594 – 0.0602)

—

Piston ring thickness

1st

0.76 – 0.81 (0.0299 – 0.0319)

1.08 – 1.10 (0.0425 – 0.0433)

—

2nd

0.77 – 0.79

(0.0303 – 0.0311)

—

Piston pin bore I.D. 15.002 – 15.008

(0.5906 – 0.5909)

15.030

(0.5917)

Piston pin O.D. 14.995 – 15.000

(0.5903 – 0.5906)

14.980

(0.5898)
