10-40 SERVICING INFORMATION
REGULATOR/RECTIFIER INSTALLATION
NOTE:
To remove or install the regulator/rectifier easily, hold its bolt
head with an open-end wrench.
1 Regulator/Rectifier 3 Clamp
2 Bracket 4 Radiator
1
4
2
1
3
2
