FI SYSTEM DIAGNOSIS 4-15
ECM TERMINAL
TERMINAL
NO.
CIRCUIT
TERMINAL
NO.
CIRCUIT
EXCVA power (MO+) * IAP sensor signal (IAPS)
Speed sensor signal + AP sensor signal (APS)
STVA signal (STVA 2A) , CKP sensor signal (CKPS–)
STVA signal (STVA 1A) - Gear position switch signal (GP)
— . Serial data for speedometer
TP sensor signal (TPS) / Power source for fuel injectors (VM)
Power source for sensors (VCC) 0 Steering damper solenoid (SSO–)
CMP sensor (CMPS+) 1 Steering damper solenoid (SSO+)
CKP sensor (CKPS+) 2 STVA signal (STVA 2B)
Power source for back-up 3 STVA signal (STVA 1B)
" Tachometer 4 —
# Power source (+B) 5 —
$ EXCVA power (MO–) 6 TO sensor signal (TOS)
% EXCVA position sensor (MPS) 7 ECT sensor signal (ECTS)
& — 8 IAT sensor signal (IATS)
' — 9 HO2 sensor (HO2S)
( — : Sensor ground (E2)
) STP sensor (STPS) ; ECU ground (E1)
