8-18 CHASSIS
FRONT FORK
CONSTRUCTION
O-ring Oil seal
Spring retainer " Oil seal stopper ring
Spacer # Dust seal
Washer $ Inner tube "
Spring " Front fork cap bolt ITEM N·m kgf-m lb-ft
Adjuster rod # Lock-nut " 23 2.3 16.5
Inner rod/Damper rod (cartridge) $ Front axle pinch bolt # 15 1.5 11.0
Outer tube % Damper rod bolt $ 23 2.3 16.5
Oil seal retainer % 23 2.3 16.5
